V6 Vertical machining center
A vertical machining center equipped with an electric spindle and an imported Fanuc system can achieve faster, more precise, and more efficient machining.
Information
- Model : V6
- Category : Vertical Machining Center
- Warranty : 12 months
- Shipping : By Sea
Key features
- Optional 12,000 rpm high-speed spindle
- Pneumatic type improves tool change stability
- Safety protection fully enclosed shield
+86 19231887520
Spindle
Okada
electrical
Schneider
System
Fanuc/Mitsubishi
OEM/ODM
YES
Specifications
Numerical control system
- Fanuc 0i-MF
- Mitsubishi M80
Work range X/Y/Z
- 600mm
- 450mm
- 510mm
Rapid traverse speed X/Y/Z
- 36m/min
- 36m/min
- 36m/min
Spindle speed
- 6000 rpm
- 8000 rpm
- 10000 rpm
- 12000 rpm
Spindle taper
- BT40
- BT50
Spindle power
- 11kW
- 15kW
Maximum torque of the table
- 52.5/95.5 Nm
Positioning accuracy
- ±0.0005/500mm
Repeat positioning accuracy
- ±0.0005/500mm
Material of the bed body
- Gray cast iron: HT250/HT300
- Ductile iron: QT450-10/QT500-7
Electrical appliance brand
- Schneider Electric
Specifications are subject to change without prior notice.
